Ideal Solution for Heavy Traffic: The F620 barrier, which spans up to 5 meters, is suitable for heavy but not continuous traffic. The barrier is supplied with a wide range of accessories, including a skirt to prevent unwanted break-ins.
Totally Flexible: The F620 barrier range is equipped with electronic deceleration at opening and closing. A version with articulated beam for low ceilings is available on request.
Long-term Reliability: Use of cutting-edge materials and treatments such as galvanized, phosphating and dust painted plus tried and tested hydraulic technology, all combine to ensure long-life.
Leading-edge Technology: SMT microprocessor electronic technology is supplied standard to ensure exceptional performance. By means of an optional card, the barrier can also control auxiliary services and an additional opposing beam.
Electronic Intelligence: The electronic intelligence of the F620 range functions by means of seven differentiated logics, the latter was expressly designed for automatic parking systems.
| Make | Neptune |
|---|---|
| Model | F-620 |
| Power Supply | 230Vac (+6% - 10%) 50 (60) Hz |
| Electric Motor | Single phase, Bi-direconal |
| Absorbed Power | 220 W |
| Absorbed Current | 1 A |
| Motor Rotation Speed | 1400 RPM |
| Pump Flow Rate | 0.75/1 L/min. |
| Thermal Protecon on motor winding | 120° C |
| Effective Torque | 0-200/0-150 Nm |
| Electronic Deceleration | Adjustable with cams |
| Thrust Capacitor | 8uF 400V |
| Operating Ambient Temperature | 20° C to +55° C |
| Weight | 73 KG |
| Type of Oil | HP Oil |
| Barrier Body Treatment | Galvanized, Phosphang and dust painted |
| Paint | RAL 2004 polyster |
| Protection Class | IP 44 |
| Type of Beam | Rectangular standard, Rectangular standard with skirt, Arculated standard, round, round pivoting |
