Top Features
1. High torque bi-direction 24VDC BLDC motor for heavy and continuous traffic.
2. Boom arm is made of extruded aluminum alloy in elliptical shape with provision for rubber gasket at bottom and rubber red plastic cover on top to accommodate LED strip.
3. Elliptical cross section of boom arm is having better resistance to wind speed wall thickness of boom arm 1.6 mm.
4. Single length of boom up to 5 meters for more length with invisible joint kit.
5. In-built encoder offers smooth & low noise operation Pre-configurable smooth movement & safety feature.
6. Reverse on contact obstacle detection safety standard.
7. Barrier housing made of 2 mm thick galvanized further reinforced load carrying area of motor mounting.
8. Programmable opening and closing speed.
9. Programmable deceleration during opening and closing for smooth landing with jerk.
10. Programmable motor force as per boom arm length and load.
11. Version available for left and right hand.
12. Modern design with removable top cover.
Optional Accessories
1. Pendulum support
2. Photocell
3. Loop detector
4. Fixed support
5. Skirt kit
Application Areas:
| Make | Neptune |
|---|---|
| Model | Power Fusion XD |
| Power Supply | 220 - 240V AC ~ 50/60 Hz |
| Electric Motor | 24V DC brushless |
| Maximum Power | 200 Watt |
| Maximum Torque | 400 - 600 Nm |
| Opening/closing speed | 2.5 to 5 Second |
| Surface Treatment | Pre hot dip galvanized and dust painted |
| Encoder | Integrated with motor |
| Beam Type | Elliptical with rubber gasket and plastic |
| Protection Class | IP 65 |
| Use Frequency | 100 % |
| Ambient Temperature | -30 ~ 60 C |
| Relative Humidity | 95 % |
| Operation Cycle | 10 million cycle |
| Remote control distance | ~ 30 mtr. |
| Height Of Boom | 900 mm from centre |
| Output of LED | 12V 5Amp. |
| Max. boom length | 8 Mtr. |
| Certification | CE |
