1. Super silent design: the machinery adopts silent design, running smoothly without impact noise.
2. Super bright indication function: the direction indication adopts super bright LED light design, the indication is more eye-catching.
3. Compatible with IC, ID, barcode, face recognition and other control devices.
4. Anti-collision function: the gate locks when the pedestrian does not swipe the card to push the gate.
5. Automatic reset function: if the card is not passed within the specified time, the gate will return to the original position and cancel the passage, the time is adjustable from 1 to 60 seconds.
6. Emergency power failure function: after the power failure, the gate is automatically in the free push open state and can be opened on both sides.
7. With standard input and output interfaces, it is the best choice for system integrators.
| Make | Neptune |
|---|---|
| Model | GS - 2048 |
| Input Power Supply | 220V AC, 50Hz |
| Power Output | 12V DC, 10Amp |
| Structure shell material | SS-304 |
| Structure shell thickness | 1.5 mm |
| Swing arm material | Acrylic organic board |
| Swing arm thickness | 10 mm |
| Size of stopper | 500 mm * 800 mm |
| Dimension | Dia.168 mm x Height 980 mm |
| Single machine power | Static 40W, Dynamic 200W |
| Passing mode | Single/Bi-directional selectable |
| Swing range | 90 degree left and right |
| Channel width | 400 - 900 mm |
| Passing Speed | 30 - 40 people/min. |
| Input Signal | Dry contact signal |
| Communication interface | RS 485 standard |
| Gate opening and closing time | 2 sec. |
| Instantaneous noise | <_ 50db |
| Working temperature | -10 C +70 C |
| Relative humidity | < 90%, no condensation |
| Net weight of the gate | 80 Kg |
| Ingress Protection | IP 44 |
| Normal service life | 10 Million Times |
| Time required to enter the passage state after power up | 5 sec. |
| Gate composition | Cylinder, swing arm, integral cylinder movement, controller, switching power supply, brushless motor (or servo motor), brushless main control board |
